WCF-1 COMPLIANCE API
Wireless Communications Fix One — Governance Interface (Public Spec, Logic Sealed)
This defines the public interaction surface for operators to integrate with the WCF-1 governance layer. All equilibrium, PHM, Sentinel, NashMark, BCE/EEE logic remains sealed inside the service. The API returns decisions and scores only never internal parameters.
1. General
Base URL (conceptual):
https://wcf1.truthfarian.net/api/v1/
Auth:
- Mutual TLS and/or OAuth2 bearer token (implementation-specific).
- All requests must be authenticated and traceable to a licensed operator and registered site.
Core IDs:
operator_id– licensed entitysite_id– physical site (tower, rooftop, mast)node_id– specific radio/antenna nodebeam_id– logical RF channel (optional)
Core enums:
{
"service_class": [
"emergency",
"medical",
"environment",
"civic_essential",
"general",
"discretionary"
],
"decision": [
"permit",
"shape",
"reduce",
"deny"
],
"system_state": [
"normal",
"constrained",
"restricted",
"critical",
"locked"
]
}
2. /sentinel/event
POST /sentinel/event
Submit ecological + field sensing for a beam/node; receive updated state + constraints.
Request
{
"timestamp": "2025-12-03T16:05:00Z",
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"node_id": "NODE-SEC-01",
"beam_id": "BEAM-01",
"sensors": {
"avian_density": 0.42,
"insect_density": 0.88,
"field_drift_index": 0.15,
"environment_disruption_index": 0.33,
"exposure_density": 0.72
},
"context": {
"local_time": "2025-12-03T16:05:00+00:00",
"season_code": "WINTER",
"weather_code": "CLOUDY",
"migration_phase": "ACTIVE"
}
}
Response
{
"system_state": "constrained",
"recommendation": {
"decision": "shape",
"max_duty_cycle": 0.35,
"max_exposure_density": 0.50
},
"breach_flags": {
"wildlife_proximity": true,
"exposure_limit": false,
"phm_harm": false
},
"audit_id": "AUD-20251203-0001"
}
3. /transmission/permission
POST /transmission/permission
Request
{
"timestamp": "2025-12-03T16:05:05Z",
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"node_id": "NODE-SEC-01",
"beam_id": "BEAM-01",
"service_class": "general",
"rf_profile": {
"frequency_mhz": 3500,
"bandwidth_mhz": 40,
"tx_power_dbm": 40,
"antenna_gain_dbi": 18,
"beam_elevation_deg": 5,
"beam_azimuth_deg": 120
},
"traffic_profile": {
"requested_throughput_mbps": 120,
"expected_duration_s": 60,
"user_count": 43
}
}
Response
{
"decision": "reduce",
"constraints": {
"max_tx_power_dbm": 32,
"max_throughput_mbps": 60,
"max_duty_cycle": 0.5
},
"system_state": "constrained",
"harm_score": {
"delta_omega": 0.27,
"delta_c": 0.39,
"equilibrium_ok": true
},
"notes": [
"wildlife_proximity_elevated",
"service_class_below_emergency"
],
"audit_id": "AUD-20251203-0002"
}
4. /exposure/check
POST /exposure/check
Request
{
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"scenarios": [
{
"scenario_id": "SCN-001",
"rf_profile": { "...": "..." },
"geometry": {
"height_m": 35,
"terrain_code": "URBAN",
"nearby_habitats": ["wetland", "hedgerow"]
}
}
]
}
Response
{
"results": [
{
"scenario_id": "SCN-001",
"max_exposure_density": 0.81,
"equilibrium_ok": false,
"recommended_adjustments": {
"max_tx_power_dbm": 30,
"max_beam_elevation_deg": 3
}
}
]
}
5. /harm/score
POST /harm/score
Request
{
"timestamp_start": "2025-12-03T16:00:00Z",
"timestamp_end": "2025-12-03T16:05:00Z",
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"node_id": "NODE-SEC-01",
"beam_id": "BEAM-01",
"summary": {
"average_tx_power_dbm": 36,
"average_exposure_density": 0.64,
"average_loss_factor": 0.22,
"material_footprint_index": 0.10
}
}
Response
{
"delta_omega": 0.31,
"delta_c": 0.42,
"equilibrium_ok": true,
"phm_class": "low_to_moderate",
"audit_id": "AUD-20251203-0003"
}
$ \Delta\Omega_t = \alpha L_t + \gamma X_t + \zeta M_t,\quad \Delta c_t - \Delta\Omega_t \ge 0 \Rightarrow \text{equilibrium\_ok} = \text{true} $
6. /state/transition
POST /state/transition
Request
{
"timestamp": "2025-12-03T16:05:10Z",
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"node_id": "NODE-SEC-01",
"requested_state": "normal"
}
Response
{
"enforced_state": "restricted",
"reason": [
"recent_breach_events",
"elevated_wildlife_proximity"
],
"unlock_time": "2025-12-03T16:25:10Z",
"audit_id": "AUD-20251203-0004"
}
7. /equilibrium/status
GET /equilibrium/status
Response
{
"operator_id": "OPR-00123",
"site_id": "SITE-ALBION-001",
"current_state": "constrained",
"equilibrium_ok": true,
"rolling_window": {
"window_s": 3600,
"aggregate_delta_omega": 3.21,
"aggregate_delta_c": 4.02
},
"recent_breaches": [
{
"timestamp": "2025-12-03T15:32:11Z",
"type": "wildlife_proximity",
"resolved": true
}
]
}
$ \text{Eq}(\mathcal{S}) = \Sigma_{t \in W}(\Delta c_t - \Delta\Omega_t) $
8. Integration Loop (Operator-Side Pseudocode)
loop:
E_t = collect_sentinel_sensors()
sentinel_resp = POST /sentinel/event(E_t)
if sentinel_resp.system_state in { "critical", "locked" }:
hard_shutdown_rf()
continue
req = build_transmission_request(sentinel_resp)
perm = POST /transmission/permission(req)
if perm.decision == "deny":
suppress_transmission()
else if perm.decision in { "shape", "reduce" }:
apply_constraints(perm.constraints)
transmit_within_envelope()
else:
transmit_nominal()
log_audit_ids(sentinel_resp.audit_id, perm.audit_id)
end loop
All governance responsibility is centralised in the WCF-1 service. Operator equipment becomes a compliant actuator that obeys: state, decision, constraints, and equilibrium signals. Internal PHM, Sentinel, NashMark, BCE, and EEE logic never leave the sealed module.
